Product – Positive Displacement Pump
Positive Displacement Pump
Abrasive Liquid Transfer Pumps
| Brand | Floroxi Pumps |
| Material | SS |
| Max Flow Rate | 500-50000LPH |
| Head | 50mtr |
| Capacity (m Cube/Hr) | 50 |
| Pressure (kg/Cm Square) | 6 |
| Viscosity (cst) | 30000 |
| Model | FPI |
| Temperature (deg. Celsius) | 120 |
| Power Source | 1-25HP |
| Speed (RPM) | 100-650 |
| Voltage (V) | 415 |
| Discharge Size (mm) | 1 |
Field of application:
Acidic and Alkaline Slurry , Alum, Bentonite Slurry , Black Liquor, casein Slurry , Clay Slurry, Coating Mix, Detergent Slurry, Electroplating Solution, Emulsions, Ferrite Slurry, fuel Oil Sludge, Glue, Grout Mix, Lube Oil, Malasses, Paint, Paper Pulp, Printeng
Ink, Resins, Sewage Sludge, soap stock, sodium silicate, sulphited sugar Juice, Varnish, vegitebale Oil, gum, sludge, viscose, yeast, Petroleum Jelly Etc.
Features
Torsion free metol – bonded stator for increased stator life, higher efficiency and per stage pressure Double-seated universal joints for smoother power transmission and longer service life of critical components .
Worke on the uniqe Progressive Cavity Principale. Inherently non-clogging and capable of handing a high percentage of solids.
Positive displacement, inherently self- priming and capable of handing enterapped gases.
Low internal velocity of fluid within the pump ensures low shear and minimizes wear due to erosion.
Low NPSH requirement results in higher suction lift up to 8.4 meters of water column.
Continuous pulsation – free flow with minimum turbulence. Flow rate propotional to the pump speed.
Capable of developing high pressure 48 Bar – even at a low pump speed.
Handles only liquid from water to abrasive slurry and froth to highly viscous media.
KNOW MORE
Progressive Cavity Pumps designed for handling Food Products, Pharmaceuticals, and Cosmetics- wherever bacteria and contamination must be avoided, or where frequent clean-up is required due to product and / or process changes. They meet national & international sanitation requirements. We not only supply pumps that are CIP and SIP capable but we also offer planning and designing for your entire pumping applications.
Capacity :Up to 50 m3/hr.
Pressure Stage :6, 12, 18 & 24 Bar
Temperature :Up to 150°c/302°F
Viscosity :Up 30,000 cST
Solid Handling Capability : Up to 25%
ump
Chemical Screw Pumps
| Capacity | Up to 50 m3/hr |
| Temperature | Up to 150°c/302°F |
| Solids Handling Capacity | Up to 7% |
| Viscosity | Up to 30,000 cST |
| Pressure Stages | 6, 12, 18 & 24 Bar |
This type of pumps find their place of applications in almost all the industries in the engineering world. Be it coal slurry or volatile chemicals, harsh abrasives or fibrous pulps, these pumps are preferred better as right choice. Whenever the pumping is found difficult, these pumps do their duty as per the user’s requirement..
Sludge /Slurry Positive Displacement Pumps
Capacity – up to 75m3/hr, Pressure-up to 12 Bar , Temprature-1200 C, Viscosity-10,00,000 CST
Field Of Application:
Acidic and Alkaline Slurry, Alum, Bentonite Slurry, Casein Slurry, Ceramic Slurry , Coating Mix , Detergent Slurry Dewatered sludge,
Electroplating Solution, Emulsions, Ferrite slurry, Flocclent, Glue Mix, Gum Sludge, Industrial wastes, Latex, Lube Oil Magmo, Massecuit, Malasses, Oil sludge, Paint Paper Pulp, Petroleum Jelly , Polyelectrolyte, Printing ink, Resins, soap Stok, Sodium, Silicate, Spent Wash, Varnish, Vegetable Oil, Viscose, Water To Thickened Sludge, Yeast etc.
Features:
Compact Configuretion of Screw Pumps in which The Pumping Parts are coupled directly to the drive thereby eliminating the Bearing Housing Suitable fo restricted 0f operation or mobile pump Sels apart from lowvaride applications in CI, CS, SS304, SS3016 etc, while Stators will be of Natural , Nitrile, EPDM, Neoprene, Hypalon, Vitan, Silicon, Butyl, Hi – Nitrile, Buna Poly Butadiene etc.
