Screw Pumps

Bio Gas slurry Pumps

Brand	Floroxi Pumps
Capacity	Up to 50 m3/hr
Temperature	Up to 150 Degree C
Solids Handling Capacity	up to 100 mm
Viscosity	Up to 100,000 cst
Solids Consistency	as high as 90%

We offer to our honored patrons the first-class range of Screw Pumps. Furthermore, our patrons can avail this product from us at affordable rates.

Eccentric Single Screw Pumps

Brand	Floroxi Pumps
Capacity	upto 100M3/hr
Pressure	up to 24 Bar
Viscosity	Up to 100,000 cst
Temperature	Up to 150 Degree c

We are specialized in offering Screw Pump to our customers. Our presented product is extremely used in the market owing to their top features.

Field of application:

Acidic and Alkaline Slurry , Alum, Bentonite Slurry , Black Liquor, casein Slurry , Clay Slurry, Coating Mix, Detergent Slurry, Electroplating Solution, Emulsions, Ferrite Slurry, fuel Oil Sludge, Glue, Grout Mix, Lube Oil, Malasses, Paint, Paper Pulp, Printeng

Ink, Resins, Sewage Sludge, soap stock, sodium silicate, sulphited sugar Juice, Varnish, vegitebale Oil, gum, sludge, viscose, yeast, Petroleum Jelly Etc.

Features

Torsion free metol – bonded stator for increased stator life, higher efficiency and per stage pressure Double-seated universal joints for smoother power transmission and longer service life of critical components .

Worke on the uniqe Progressive Cavity Principale. Inherently non-clogging and capable of handing a high percentage of solids.

Positive displacement, inherently self- priming and capable of handing enterapped gases.

Low internal velocity of fluid within the pump ensures low shear and minimizes wear due to erosion.

Low NPSH requirement results in higher suction lift up to 8.4 meters of water column.

Continuous pulsation – free flow with minimum turbulence. Flow rate propotional to the pump speed.

Capable of developing high pressure 48 Bar – even at a low pump speed.

Handles only liquid from water to abrasive slurry and froth to highly viscous media.

Butter Transfer Pump

Brand	Floroxi Pumps
Capacity	Up to 50 m3/hr
Temperature	Up to 150 Degree C
Viscosity	Up to 100,000 cst
Cleaning	SMS Connection

Our presented range of SMS Connection Butter transfer Pump is broadly employed in the market for their durable nature. Due to their top features, these are enormously demanded in the market.

Application Field:

Fruit Juice, Fruit Pulp, Tomato Paste, Amla Pulp, Beer, Beverages, Butter, oil, Cream, Curd, Demineralised water, Diced Vegetables, Glucose, Ice-Cream mix, Jams, Latex, Liquor, Lotions and creams, Malt extract, Medical Formulations, Milk, squashes, sugar syrup, Tarmarind extract, tooth paste, Vegetable refined oil, wine etc.

MOC

Rotor / Shaft & Rotating Parts in AISI 304, AISI 316 & AISI 316L

Stainless Steel Tube Rubber Stator in Nitrile, Hyplon, NCR Food Grade Nitrile, EPDM in white & black colour Rubber.

Shaft Sealing by Stuffing Box Gland Packed / Mechanical Seal

Single Screw Pumps

Brand	Floroxi Pumps
Capacity	Up to 50 m3/hr
Temperature	150 Degree C
Viscosity	100,000 cst
Pressure	up to 24 Bar

Owing to devoted experts, we have been competent to present a wide range of Single Screw Pump. These products are made as per industry norms and standards.

Positive Displacement Pump

Brand	Floroxi Pumps
Capacity	50 m3/hr
Temperature	Up to 150 Degree C
Solids Handling Capacity	up to 7-10%
Viscosity	Up to 5,000 cst

Owing to the vast acquaintance, our firm is competent to present Food Grade Screw Pumps. Our customers can avail this product as per their requirements.

Molesses Transfer Pump

Technical Specifications:

Capacity (Flow Rate)	Up to 60000 LPH
Discharge Pressure	12 Bar, 24 Bar & 36 Bar
Viscosity	100000CST
Temperature	150Deg C

Application Field:

Molasses, Paint, Paper Pulp, Printing Ink, Resins, Sewage Sludge, Vegetable Oil, gum, sludge, yeast, Petroleum Jelly, Acidic and Alkaline Slurry , Alum, Bentonite Slurry , Black Liquor, casein Slurry , Clay Slurry, Coating Mix, Detergent Slurry, Electroplating Solution, Emulsions, Ferrite Slurry, fuel Oil Sludge, Glue, Grout Mix, soap stock, sugar Juice, Varnish Etc.

Features:

All metallic parts in contact with the fluid are in smooth finish Stainless Steel.

Stator is of non-contaminating Polymer which is resistant to oil and fats.

All internal of contours are designed to be swept by the product flow or by a detergent when in-line cleaning.

Elimination of product retaining pockets avoids chemical or bacterial contamination.

Simple Constructions allows Quike dismantling.

Can work against high vacuum. Ideal for lifting viscous fluids from the vacuum pan .

Law fluid velocities ensures gentle handling of shear sensitive fluids without damage .

Pulsation, turblelnce or aeration-free metered flow propotional to speed .

Capacity varied by simple variation of pump speed to match system paramieters .

Single Screw Pump

Technical Specifications:

Capacity (Flow Rate)	Up to 80000 LPH
Discharge Pressure	12 Bar, 24 Bar & 36 Bar
Viscosity	100000CST
Temperature	120Deg C
